UG: 20T Hydraulic Spooler
The SM0038 20 Tonne Hydraulic Spooler is a hydraulic hold-back tension spooler designed for controlled spooling operations in offshore and industrial environments. It supports both over- and under-spooled configurations, delivers up to 6000 kg pull at 210 bar, and handles drums up to 20,000 kg with flange diameters up to Ø4100 mm or Ø4700 mm with extenders.
The unit is fitted with an automatic drum brake, Staffa B 200 / S hydraulic motor, and controls for heave/lower, ram in/out and CT.
The SM0038 20 Tonne Hydraulic Spooler is a hydraulic hold-back tension spooler designed for controlled spooling operations in offshore and industrial environments. It supports both over- and under-spooled configurations, delivers up to 6000 kg pull at 210 bar, and handles drums up to 20,000 kg with flange diameters up to Ø4100 mm or Ø4700 mm with extenders.
The unit is fitted with an automatic drum brake, Staffa B 200 / S hydraulic motor, and controls for heave/lower, ram in/out and CT.
Features
Hydraulic hold-back tension spooler
Suitable for both over-spooled and under-spooled operation
Automatic drum brake for controlled handling
Designed for heavy-duty drum handling up to 20 tonnes
Multiple shaft size compatibility
Hydraulic motor-driven operation
Integrated lifting arrangement
Mobile unit design for offshore and industrial spool handling
Specifications
| Availability |
|---|
Please refer to data sheet for complete specifications.
Applications
Offshore cable spooling operations
Umbilical handling and reeling
Hose spooling and de-spooling
Tension-controlled drum handling
Overboarding and recovery support operations
Offshore installation and mobilisation projects
