Sonardyne Compatt 6G®
Compatt 6 offers significant time saving using faster and more robust Sonardyne Wideband®2 acoustic ranging and telemetry protocols. This makes any system operating with Compatt 6
significantly easier to operate therefore de-risking operations, reducing vessel time and reducing training requirements for offshore personnel. Sonardyne Wideband 2 advanced signal processing offers improved acoustic performance in challenging conditions, longer range, improved multipath rejection around structures and real-time range diagnostics for quality control.
Sonardyne Wideband 2 also reduces the interference to and from adjacent Sonardyne and other acoustic positioning systems. The integrated communications and navigation technology allows the transponder to be used as a multipurpose modem, autonomous data logger and navigation reference transponder.
Features
Faster setup using new telemetry commands
Data storage and retrieval in Compatt 6 such as installed array coordinates
Standard sensors – temperature, pressure and MEMS inclinometer
Available with optional Sound Velocity and Inclinometer sensors
Specifications
| Availability |
|---|
System Accuracy: Subsea target tracking to centimetric accuracy independent of depth
LBL Calibration: Batched baseline and batched simultaneous baseline collection
Survey Inputs/Outputs: All industry-standard Survey telegrams and proprietary Sonardyne NMEA
Ranging Precision: Better than 0.015m
Array Size: 99+
Applications
Installing subsea structures
Tracking ROVs
Conducting acoustic metrology
Simultaneous baseline calibration
-
