BIRNS: General-Area Chamber Light LED™


The robust BIRNS General-Area Chamber Light-LED™ (BIRNS model 4132) is an innovative, versatile fixture that safely provides brilliant lighting inside HeO2-atmosphere PVHO chambers. Crafted from rugged hard black anodized aluminum, with a tempered borosilicate glass lens, it integrates a stainless steel cage for additional lamp protection and can be specified with an added connector and/or on/off switch.


Brilliant white light LED illumination

Low power draw

50,000 hour lamp life

Can mount on practically any ceiling or wall

Complete safety: Case ground (earth)


Height: 109 mm (4.3 in.); Diameter of body: Ø81 mm (Ø3.2 in.); Diameter of base: Ø122 mm (Ø4.8 in.)

Mounting holes: 2 x Ø6.1 mm (Ø.24 in.) holes on Ø97 mm (Ø3.82 in.) bolt circle

Weight in Air: 544 g (1.2 lb)

Lamp Type: LED (15 High Output LED elements)

Time To Full Brightness: <1 second after application of power


Delivers white light illumination inside pressurised chambers.
