Survey Equipment

Hydro-Lek HLK-2150: Pan and Tilt

Availability: Sale

The HLK-2150 pan and tilt is a compact, light-weight, medium duty hydraulic pan and tilt unit designed to work reliably on all types of submersible systems.

Features

Porting available in 1/8? BSPP or 7/16? SAE in accordance with ISO 1179 & SAE J1926-1 respectively

Constructed from corrosion resistant materials

Compact and lightweight at only 3.4kg (7.5lb) in water

Pan travel of 360 degrees and a tilt travel of 180 degrees

Specifications

Operational depth: 3000msw (9,840ft)

Materials: 316 Stainless Steel, 6082 Aluminium

Dimensions: (H) 260mm x (W) 229mm x (D) 77mm (10.2″ x 9″ x 3″)

Pan travel: 360 degrees

Tilt travel: 120 degrees

Applications

Ideally suited for the positioning of cameras, lights or survey equipment

Can be installed to the end of camera booms for pipe inspection activities.
